SPARTAN 1.5,2.0HPx240V SUBMERSIBLE PUMP

SHOWFOU ELECTRONIC CONSTANT PRESSURE PUMP
SPARTAN VERTICLE SUBMERSIBLE PUMPS SERIES

Description

SPT-4SD-4/16-1.5,2.0HPx240V

APPLICATIONS & SALIENT FEATURES

  • Suitable for lifting, pressurizing and distribution in civil, industrial applications, fire fighting and washing plants. It also draws from wells, tanks or natural basins.
  • The radial hydrodynamic layout reduces the axial dimensions of the hydraulic elements, allowing an elevated number of stages to be used in order to obtain high pressures with modest flows.

OPERATION DATA

  • Fluid: chemically and mechanically non-agressive with a maximum solid substance content equal to the hardness and grain size of silt (40g/m3)
  • Max temperature: 300C
SKU: 3602 Categories: , ,
